| Product Attribute | Attribute Value |
|---|---|
| Actuator Type | Side Roller Plunger |
| Body Style | Plug-in |
| Contact Form | SPDT |
| Contact Material | Silver |
| Current Rating | 10 A |
| Family Name | LS Series Family |
| Head Type | Plunger |
| Material | Zinc Die-Cast (Housing) |
| Material, Casing | Zinc Die-Cast |
| Mounting Hole Size | Mount by either of two methods: (a) use two #10 screws from the front, or (b) use two #10-32 UNF screws from the back. |
| Operating Force | 6 lb. (Max.) |
| Operating Temperature | -12 to 93 °C |
| Series | |
| Standards | UL listed, CSA certified. |
| Termination | Screws |
| Type | Limit |
| Voltage Rating | 600 VAC |
Overview
Honeywell HDLS Series - MICRO SWITCH Heavy-Duty Limit Switches:
Honeywell’s MICRO SWITCH heavy-duty limit switches’ modular construction allows for a wide variety of actuator styles, operating heads, and electrical circuitry options. The plug-in versions greatly reduce downtime on production lines with high actuation rates as replacement of the switch is accomplished in seconds. The base receptacle contains all the wiring and conduit connection while the switching component with operating head easily assembles to the base and is attached with two screws. They are ideal for many applications with demanding indoor and/or outdoor environments, where they may be subjected to shock or vibration from equipment, temperature extremes, dust, splashing water, coolant, and/or hose-directed water.
